Camera | |
Image Sensor | 1/3" Progressive Scan CMOS |
Min. Illumination | Color: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR, |
Color: 0.028Lux @ (F2.0, AGC ON), 0 Lux with IR | |
Shutter Speed | 1/3 s to 1/100,000 s |
Slow Shutter | Yes |
Day & Night | IR Cut Filter |
Digital Noise Reduction | 3D DNR |
WDR | 120dB |
3-Axis Adjustment | Pan: 0° to 360°, tilt: -75° to 65°, rotate: 0° to 360° |
Lens | |
Focal length | 1.68 mm |
Aperture | F2.0 |
FOV | Horizontal field of view: 180°, Vertical field of view: 85° |
Lens Mount | M12 |
IR | |
IR Range | 10 m |
Wavelength | 850nm |
Compression Standard | |
Video Compression | Main stream: H.265/H.264 |
Sub stream: H.265/H.264/MJPEG | |
H.264 Type | Main Profile/High Profile |
H.264+ | Yes |
H.265 Type | Main Profile |
H.265+ | Yes |
Video Bit Rate | 32 Kbps to 8 Mbps |
Audio Compression | G722.1/G711ulaw/G711alaw/G726/MP2L2/PCM |
Audio Bit Rate | 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2) |
Smart Feature-set | |
Region of Interest | Support 1 fixed region for main stream and sub-stream separately |
Image | |
Max. Resolution | 2304 × 1296 |
Main Stream | 50Hz: 20fps (2304 × 1296), 25fps (1920 × 1080, 1280 × 720) |
60Hz: 20fps (2304 × 1296), 30fps (1920 × 1080, 1280 × 720) | |
Sub Stream | 50Hz: 25fps(640 × 360, 480 × 272, 432 × 240) |
60Hz: 30fps(640 × 360, 480 × 272, 432 × 240) | |
Image Setting | Saturation, brightness, contrast, sharpness adjustable by client software or web browser |
Image Enhancement | BLC/3D DNR |
Day/Night Switch | Auto/Schedule |
Network | |
Network Storage | Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR |
Alarm Trigger | Motion detection, video tampering, network disconnected, IP address conflict, HDD full, HDD error, illegal login |
Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, IGMP, QoS, IPv6 |
General Function | One-key reset, anti-flicker, dual streams, heartbeat, password protection, privacy mask, watermark |
API | ONVIF (PROFILE S, PROFILE G), ISAPI |
Simultaneous Live View | Up to 6 channels |
User/Host | Up to 32 users |
3 levels: Administrator, Operator and User | |
Client | iVMS-4200, Hik-Connect, iVMS-5200 |
Interface | |
Audio | 1 built-in mic, 1 built-in speaker, two-way audio, mono sound |
On-board storage | Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
Reset | Yes |
SVC | Support H.264 and H.265 encoding |
Wi-Fi | |
Wireless Standards | IEEE 802.11b/g/n |
Frequency Range | 2.412 GHz to 2.4835 GHz |
Channel Bandwidth | 20M/40M |
Protocols | 802.11b: DQPSK, DBPSK, CCK |
802.11g/n: OFDM/64-QAM, 16-QAM, QPSK, BPSK | |
Security | WPA, WPA2 |
Transfer Rates | 11b: 11Mbps, 11g: 54Mbps, 11n: up to 150Mbps |
Wireless Range | 50 m |
Audio | |
Environment Noise Filtering | Yes |
Audio Sampling Rate | 16 kHz, 32kHz, 44.1kHz, 48kHz |
General | |
Operating Conditions | -10 °C to +40 °C (14°F to +104 °F), Humidity 95% or less (non-condensing) |
Power Supply | 5 VDC ± 10%, micro USB |
Power Consumption and Current | 5 VDC, 1A, max. 6.5W |
Interface Protection | TVS 2000V Lightning Protection, Surge Protection and Voltage Transient Protection |
Material | Bracket: metal |
Camera shell: plastic | |
Dimensions | Φ78.1 mm × 110.2 mm (Φ3.07" × 4.34") |
Weight | Camera: Approx. 230 g (0.51 lb.) |
