Image Sensor | Uncooled Focal Plane Arrays |
Max. Resolution | 160 × 120 |
NETD | < 40mk (@ 25 °C,F#=1.0) |
Field Of View | 37.2° × 50 ° |
Aperture | F 1.1 |
Pixel Pitch | 17μm |
Focal Length | 3.1 mm |
IFOV (Mrad) | 5.48 mrad |
Response Waveband | 8μm to 14μm |
Monitor |
320 × 240 resolution 2.4’ LCD display
|
Palettes |
Black hot, White hot, Rainbow, Ironbow
|
Rules |
3 thermometry points: Max. Temperature; Min. Temperature; Center Temperature
|
Thermometry Range |
-20 °C to 550 °C (-4 °F to 1022 °F)
|
Thermometry Accuracy | Max (±2 °C, ±2%) |
Battery Type |
Rechargeable Lithium Battery
|
Battery Operating Time | 8 hours continuous running |
Functions | Laser Light |
Storage |
Replaceable memory card (default 8G, support up to 128G storage)
|
Photo | Thermal image |
Video | N/A |
Language | English |
General | Power |
3.7 V DC/0.4 A | Power Consumption |
Less than 1.2 W | Weight |
Approx | less than 350 g (0.77 lb) |
Hardware | Interface |
micro USB | Protection Level |
IP54 | Drop Test Height |
2 m (6.56 feet) | Dimension |
Accessory |
196 mm × 117 mm × 59 mm (7.7 ″ × 4.6 ″ × 2.3 ″)
|
Working Temperature |
-10 °C to 50 °C (14 °F to 122 °F)
|
