| Camera |
| Image Sensor |
1/1.8-inch progressive scan CMOS |
| Min. Illumination |
Color: 0.0014Lux @ (F1.0, AGC ON), 0 Lux with white light |
| Shutter Speed |
1/3s to 1/100,000s |
| Slow Shutter |
Yes |
| Wide Dynamic Range |
120dB |
| Angle Adjustment |
Pan: 0 to 360°, tilt: 0 to 90°, rotation: 0 to 360° |
| Lens |
| Lens |
2.8/4/6 mm, fixed lens |
| FOV |
2.8 mm, horizontal FOV: 102°, vertical FOV: 51°, diagonal FOV: 125°
4 mm, horizontal FOV: 89°, vertical FOV: 46°, diagonal FOV: 105°
6 mm, horizontal FOV: 54°, vertical FOV: 30°, diagonal FOV: 62° |
| Aperture |
F1.0 |
| Lens Mount |
M16 |
| Illuminator |
| White Light Range |
30m |
| Video |
| Max. Resolution |
2560 × 1440 |
| Main Stream |
50Hz: 25fps (2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz: 24fps (2560 × 1440), 30fps(2304 × 1296, 1920 × 1080, 1280 × 720) |
| Sub Stream |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Video Compression |
Main stream: H.265+/H.264+/H.265/H.264
Sub-stream: H.265/H.264/MJPEG |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| H.264 Type |
Baseline Profile, Main Profile, High Profile |
| H.265 Type |
Main Profile |
| Stream Type |
Main stream/Sub-stream/third stream |
| Simultaneous Live View |
Up to 6 channels |
| Scalable Video Coding (SVC) |
Yes |
| Region of Interest (ROI) |
1 fixed region for each stream |
| Network |
| API |
ONVIF (PROFILE S, PROFILE G), ISAPI, SDK |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| User/Host |
Up to 32 users. 3 user levels: administrator, operator and user |
| Security |
Password protection, complicated password, HTTPS encryption, watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication
for ONVIF, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2 |
| Network Storage |
microSD/SDHC/SDXC card (256 GB), local storage and NAS (NFS,SMB/CIFS), ANR |
| Client |
iVMS-4200, Hik-Connect, Hik-Central |
| Web Browser |
IE8+, Chrome41.0-44, Firefox30.0-51, Safari8.0-11 |
| Image |
| Day/Night Switch |
Day/Night |
| Image Enhancement |
BLC, HLC, 3D DNR |
| Image Settings |
Saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser |
| S/N Ratio |
>50dB |
| Interface |
| RS-232 |
RS-232 serial port control |
| On-board Storage |
Built-in micro SD/SDHC/SDXC slot, up to 256 GB |
| Hardware Reset |
Yes |
| Communication Interface |
1 RJ45 10M/100M self-adaptive Ethernet port |
| Smart Feature-Set |
| Basic Event |
Motion detection, video tampering alarm, exception (IP address conflict, illegal login, HDD full, HDD error) |
| Premier Protection |
Intrusion detection, line crossing detection |
| General |
| Web Client Language |
English, Russian, Italian, French, Polish, Portuguese, Spanish, Turkish |
| General Function |
One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy masks, IP address conflict, flash log |
| Software Reset |
Yes |
| Linkage Method |
Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger capture |
| Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F) |
| Startup and Operating |
-30 °C to 60 °C (-22 °F to 140 °F) |
| Power Supply |
12 VDC ± 20%, PoE: 802.3af |
| Power Consumption and Current |
12VDC, 0.5 A, max. 6 W; PoE:(802.3af, 36V to 57V), 0.2 A to 0.1 A, max. 7.5 W |
| Power Interface |
Φ5.5 mm coaxial power plug |
| Material |
Metal |
| Camera Dimension |
85 × 85 × 218 mm (3.3inch × 3.3inch × 8.6inch) |
| Package Dimension |
315 × 137 × 141 mm (12.4inch × 5.4inch × 5.6inch) |
| Camera Weight |
0.710 kg (1.6 lb.) |
| With Package Weight |
1.035 kg (2.3 lb.) |
| Protection |
Ingress protection: IP67 (IEC 60529-2013) |
